Dimensions: Ø171.5 x 33 mm (Ø6.8 x 1.3")
-
WiFi standard: WiFi 7
-
Spatial streams: 4
-
Coverage area: 115 m² (1,250 ft²)
-
Max number of clients: 200+
-
Uplink: 2.5 GbE
-
Mounting locations: ceiling, wall
-
Mounting plate: plastic (included)
-
Power supply: PoE
-
MIMO:
-
5 GHz: 2x2 DL/UL MU-MIMO
-
2.4 GHz: 2x2 DL/UL MU-MIMO
-
Max data rate:
-
5 GHz: 4.3 Gbps (BW240)
-
2.4 GHz: 688 Mbps (BW40)
-
Antenna gain:
-
5 GHz: 5 dBi
-
2.4 GHz: 4 dBi
-
Max transmit power:
-
5 GHz: 24 dBm
-
2.4 GHz: 23 dBm
-
Max number of BSSID: 8 per radio
-
Supported data rates:
-
802.11be (WiFi 7): 7.3 Mbps - 4.3 Gbps (MCS0-MCS13 NSS1/2 EHT 20/40/80/160/240)
-
802.11ax (WiFi 6): 7.3 Mbps - 2.4 Gbps (MCS0-MCS11 NSS1/2 HE 20/40/80/160)
-
802.11ac (WiFi 5): 6.5 Mbps - 1.7 Gbps (MCS0-MCS9 NSS1/2 VHT 20/40/80/160)
-
802.11n: 6.5 Mbps - 300 Mbps (MCS0-MCS15 HT 20/40)
-
Features:
-
Wireless meshing: yes
-
Band steering: yes
-
802.11v BSS transition management: yes
-
802.11r fast roaming: yes
-
802.11k radio resource management (RRM): yes
-
Advanced radio control: yes
-
Passpoint (Hotspot 2.0): yes
-
Captive portal: yes
-
Customized landing page: yes
-
Voucher authentication: yes
-
Payment-based authentication: yes
-
External portal server support: yes
-
Password authentication: yes
-
Guest network isolation: yes
-
Private pre-shared key (PPSK): yes
-
WiFi speed throttling: yes
-
Client isolation: yes
-
WiFi scheduling: yes
-
RADIUS over TLS (RadSec): yes
-
Dynamic VLAN over RADIUS: yes
-
Hardware:
-
Max power consumption: 13 W
-
Voltage range: 42.5-57 V DC
-
Network interface: 1 x 2.5 GbE RJ45
-
Weight: 313 g
-
Management: Ethernet
-
Enclosure material: UV stabilized polycarbonate
-
Mounting material: UV stabilized polycarbonate, galvanized steel (SGCC)
-
System: white/blue
-
Channel bandwidth:
-
HT: 20/40 MHz
-
VHT: 20/40/80/160 MHz
-
HE: 20/40/80/160 MHz
-
EHT: 20/40/80/160/240 MHz
-
Certifications: CE, FCC, IC
-
Operating temperature: -30 to 40 °C
-
Humidity: 5-95% non-condensing
-
Software:
-
Requirements:
-
UniFi Network: version 9.0.114 or later
-
UniFi OS iOS: version 10.20.2 or later
-
Android: version 10.21.7 or later
