UniFi USW Ultra PoE 60W

The UniFi USW Ultra PoE 60W from Ubiquiti is a compact and reliable switch with integrated PoE, designed to simplify the installation of access points, surveillance cameras and VoIP phones. It combines robust performance with advanced management, making it easy to control network traffic, restrict broadcast traffic and mirror ports - while keeping the installation clean and flexible for desktop or wall mounting.

UniFi USW Ultra PoE 60W Equipped with eight gigabit Ethernet ports for stable and fast wired connectivity in smaller networks PoE capability with total power budget of 42W, including seven PoE+ ports and one 4PPoE (PoE++) port for more demanding devices Support for advanced L2 features such as rate limiting, port mirroring, broadcast storm control, multicast, and jumbo frames Compact white polycarbonate design suitable for both desktop and wall mounting, including power adapter Important to consider the total 42W PoE budget when connecting multiple power-hungry devices

Product features

• 7 GbE PoE+ output ports
• 1 GbE port with optional PoE++ input*
• 52W PoE availability with the included power adapter _ *PoE input supported for switch operation, with PoE+/PoE++ input or AC power required for PoE output_

Performance and ports The switch's eight RJ45 gigabit ports are optimized for typical office and edge traffic. With a switch capacity of 16 Gbit/s and a throughput of 8 Gbit/s, it ensures stable and efficient data management in smaller network environments. Support for jumbo frames and multicast improves performance for storage synchronization and streaming, for example.

Power supply and installation The UniFi USW Ultra PoE 60W offers PoE and PoE+ on seven ports, as well as a 4PPoE port for devices with higher power requirements. The total PoE budget of 42W allows multiple devices to be powered without the need for external injectors. For optimal operation, the total power consumption should be carefully planned. The device can be powered via DC input or compatible PoE sources, and the included power adapter simplifies installation.

Management, design and operating environment As a managed L2 switch, the model offers features such as flow control, rate limiting and port mirroring - providing good traffic control and troubleshooting capabilities. The lightweight polycarbonate enclosure allows flexible placement and easy wall mounting. The product is designed to operate in standard IT environments with a temperature range of -20°C to 45°C and a relative humidity of 10-90% without condensation. A one-year warranty is included.
